Czx-01 magnetoresistive speed sensor

Czx-01 magnetoresistive speed sensor

Czx-01 magnetoresistive speed sensor adopts the principle of electromagnetic induction to measure the speed. A coil is wound around the front end of the sensor. Its outline drawing is shown in Figure 1 and its installation is shown in Figure 2. When the gear rotates, the magnetic line of force passing through the sensor coil changes and periodic voltage is generated in the sensor coil. The speed of the gear can be measured by processing and counting the voltage. The sensor shell is made of stainless steel, with strong output signal, good anti-interference performance and convenient installation and use. It can be used in harsh environments such as smoke, oil and gas, water and gas.
